In-Store Pickup Only
Whether it’s navigating asphalt or venturing through an unpaved short cut, the Avail AR is smooth on flats, spry on climbs and confident on descents.
Comfort
The lightweight ALUXX aluminum frame features the latest endurance geometry with an Advanced-grade composite fork and D-Fuse seatpost to diminish vibrations.
Control
The 32c tires provide stability on both road and off-road surfaces, with compatibility for tubeless tires up to 38c. The OverDrive steerer and powerful disc brakes ensure precise handling and reliable stopping power, giving you confidence on any terrain.
Carrying Capacity
Equipped with frame mounts for racks and fenders, the Avail AR ensures you're ready for longer journeys with all the necessary gear and protection.
Specifications
Frame
ALUXX-grade aluminum, 12x142mm thru-axle, disc
Fork
Advanced-grade composite, full-composite OverDrive steerer, 12x100mm thru-axle, disc
Handlebar
Liv Connect
Grips
Liv All Condition
Stem
Giant Sport, 7-degree
Seatpost
Giant D-Fuse, alloy, 14mm offset
Saddle
Liv Approach
Pedals
Platform
Shifters
Shimano Claris, 1x8
Front Derailleur
Shimano Claris FD-R2000
Rear Derailleur
Shimano Claris RD-R2000 GS
Brakes
Tektro MD-C550 mechanical
Giant MPH rotors, [F] 160mm, [R] 160mm
Brake Levers
Shimano Claris
Cassette
Shimano CS-HG50, 8-speed, 11x34
Chain
KMC Z8.1
Crankset
FSA Tempo, 34/50
Bottom Bracket
Cartridge
Rims
Giant S-R2 Disc wheelset, alloy, [F] 25mm, [R] 25mm
Hubs
Giant alloy, 12mm thru-axle
Spokes
Sapim
Tires
Giant S-R3 AC, 700x32c (34mm)
Extras
Fender mount, 38mm max tire size
* Specifications are subject to change without notice
Geometry
| XXS | XS | S | M | L | ||
|---|---|---|---|---|---|---|
| A | Reach | 362 | 366 | 369 | 373 | 383 |
| B | Stack | 522 | 538 | 561 | 582 | 601 |
| C | Head Tube Angle | 70.0° | 70.5° | 71.5° | 72.0° | 72.0° |
| D | Bottom Bracket Drop | 80 | 80 | 80 | 80 | 80 |
| E | Wheelbase | 994 | 999 | 1001 | 1006 | 1022 |
| F | Chain Stay Length | 422 | 422 | 422 | 422 | 422 |
| G | Head Tube Length | 103 | 118 | 138 | 158 | 178 |
| H | Top Tube Length | 502 | 515 | 525 | 540 | 555 |
| I | Seat Tube Angle | 75.0° | 74.5° | 74.5° | 74.0° | 74.0° |
| J | Stand Over Height | 683 | 681 | 709 | 736 | 766 |
*All measurements in degrees or millimetres
Sizing Guide
| Size | Height | |
|---|---|---|
| Imperial | Metric | |
| XXS | 4'9" - 5'2" | 145 - 157cm |
| XS | 5'0" - 5'4" | 152 - 163cm |
| S | 5'2" - 5'7" | 158 - 169cm |
| M | 5'5" - 5'9" | 164 - 176cm |
| L | 5'7" - 6'0" | 170 - 182cm |
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
